Triple-Output AMOLED Display Power Supply
The SGM3836D is designed for powering AMOLED displays which require VAVDD, VELVDD and VELVSS. The device integrates two boost converters, VO1 for VELVDD and VO3 for VAVDD, and an inverting buck-boost converter VO2 for VELVSS. Output voltages of all the three converters can be programmed in digital steps through the digital interface control pin (CTRL).
The SGM3836D is available in a Green TQFN-3×3-16L package. It operates over an ambient temperature range of -40℃ to +85℃.
2.9V to 4.5V Input Voltage Range
Synchronous Boost Converter (ELVDD)
4.6V to 5.0V Output Voltage with 100mV Steps
4.6V Default Output Voltage
1% Accuracy
Output Voltage Sensing Pin for Path Loss Compensation (FBS)
Synchronous Inverting Buck-Boost Converter (ELVSS)
-5.4V to -1.4V Output Voltage with 100mV Steps
-4.0V Default Output Voltage
1.1% Accuracy at -4.0V
ELVDD & ELVSS Combined Output Current Capability
Up to 800mA at 4.6V/-2.5V (VIN = 3.1V)
Up to 780mA at 4.6V/-2.7V (VIN = 3.1V)
Up to 750mA at 4.6V/-3.0V (VIN = 3.1V)
Up to 630mA at 4.6V/-4.0V (VIN = 3.1V)
Up to 510mA at 4.6V/-5.4V (VIN = 3.1V)
Synchronous Boost Converter (AVDD)
5.8V to 7.9V Output Voltage with 300mV Steps
6.7V Default Output Voltage
1% Accuracy
100mA Output Current Capability
VIN and VOUT Bi-Directional Isolation
Short Circuit Protection (SCP)
Overload Protection
Thermal Shutdown
VELVSS Start-Up Delay: 10ms
Short Circuit and OLP Detect Time: 1ms
Available in a Green TQFN-3×3-16L Package
Smartphones & Tablets
Active Matrix OLED Displays
Part Number | Status | Package | Pins | Pd-Free | RoHS | REACH | Green | MSL Rating | Operating Temperature Range | Material Content | Reliability Report | Unit Resale Price* (Volume Range: in USD) | Lead Time** (Volume Range: Days) | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
SGM3836DYTQ16G/TR | 不推荐用于新设计 | TQFN-3×3-16L | 16 | Yes | Yes | Yes | Yes | MSL1 | -40℃ to +85℃ | 查看 | 查看 |
* 价格仅供参考。请联系我们的经销商获取正式报价。
** 交货时间仅供参考，可能会根据不同情况而发生变化。
