The 74LVC2G08 is a dual 2-input AND gate that is designed for 1.65V to 5.5V VCC operation. The device can be used as a down translator in a mixed 3.3V and 5.5V system environment. The device features the Boolean function Y = A × B or Y = A + B.
This device is highly suitable for partial power-down applications using power-off leakage current (IOFF) circuit. When the device is powered down, the current backflow will be prevented from passing through the device.
Wide Supply Voltage Range: 1.65V to 5.5V
Inputs Accept Voltage up to 5.5V
+24mA/-24mA Output Current at VCC = 3V
Low Power Dissipation
Propagation Delay: 4ns (TYP) at 3.3V
Support Live Insertion, Partial-Power-Down Mode and Back-Drive Protection
-40℃ to +125℃ Operating Temperature Range
Available in a Green VSSOP-8 Package
Wireless Basestation
Networking
Access Device
Signal Process
Notebook PC
Mobile Phone
Part Number | Status | Package | Pins | Pd-Free | RoHS | REACH | Green | MSL Rating | Operating Temperature Range | Material Content | Reliability Report | Unit Resale Price* (Volume Range: in USD) | Lead Time** (Volume Range: Days) | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
74LVC2G08XVS8G/TR | Active | VSSOP-8 | 8 | Yes | Yes | Yes | Yes | MSL1 | -40℃ to +125℃ | View | View | 1-24 units : $0.525/unit 25-99 units : $0.45/unit 100-249 units : $0.375/unit 250-499 units : $0.3/unit 500-999 units : $0.2625/unit 1000-9999 units : $0.195/unit | 3K-9K : 14 days 10K-99K : 35 days 100K-999K : 70 days 1000K and above : 91 days |
* The unit resale price is for reference purposes only. Please contact our distributors for a formal quotation.
** The lead time provided is for reference purposes only and is subject to change based on different circumstances.
